VoiceFinder AP600S is a next generation VoVPN (Voice over Virtual Private Network) gateway. It combines with functions of VPN and VoIP gateway. This is a total solution for small and middle-scale business environments. It ensures security, QoS for VoIP voice communication and even IPv6.
BcN is a converging network of data, voice and video traffic which can be realized through VoVPN (Voice over Virtual Private Network) gateway. VoiceFinder AP600S is suitable for companies require high-performance, multi-functional VPN services along with VoIP functions at once. It supports not only protocols such as PPPoE for XDSL, cable modem connection but also various routing protocols such as Static and IEEE 802.1Q VLAN Routing, RIP v1/v2, OSPF v2, BGP v4. This is also designed to support VoIP protocols such as SIP, MGCP, H.323 concurrently.
AP600S as VoIP Gateway
AP600S maintains high quality of AddPac's VoIP gateway series which have been developed through years of experiences and know-how in telecommunication and enterprise markets. It supports VoIP signaling protocols such as H323, SIP, MGCP concurrently. As VoIP service grows, there are increasing cases of using different VoIP protocols with different ITSP (Internet Telephony Service Provider)s. In this aspect, AP600S supports three main VoIP protocols concurrently so that any types of ITSP can be used. Offering this powerful VoIP feature, AP600S fulfills the demands of customers with high expectations.
AP600S as VPN Gateway
AP600S provides hardware accelerator as an option for VPN security. This controls network and system traffics enabling excellent VPN service. Based on AddPac's own embedded OS, APOSTM, it delivers reliable VPN, VoIP service and wide area network expansion service which can be adopted in any network environments. Also it is capable of using various algorithms such as DES, 3DES, AES so it is suitable for encryption algorithm and security policy.
The power of converging VoVPN gateway
- Approved QoS feature: QoS (Quality of Service) function enables to control multimedia traffics effectively by reducing packet loss or transfer delays. AP600S offers excellent performance on processing multimedia data such as images, VoIP etc using QoS along with AddPac's own QoS service.
- Automatic network security function: even for a small enterprise branch needs to have security system for critical data applications and confidential calls from head office. It has to be prevented and protected by reliable security system. However, it is not easy for small business companies to realize and often unpredicted problems can be faced without IT expert. AP600S ensures network protection through the functions of VPN and VoIP. It guarantees secure internet communications using embedded 4 ports 10/100Mbps hub which also has auto secure networking configuration function.
- Solid VoVPN solution: AP600S is a converged networking system with features of sharing public IP, routing service, NAT/PAT, DHCP Server/Relay. In order to adopt various network environments it is essential to support various networking services such as XDSL, cable network, FTTH, metro Ethernet, metro ATM, leased line, flexible IP, cutting-edge QoS (Quality OF Service) as well as security. In this aspect, AP600S offers 1-port 10/100Mbps fast Ethernet for WAN connection and 4 ports 10/100Mbps switching hub for LAN connection. Ultimately AP600S delivers converged network services such as high-performance LAN-to-LAN Routing, bridge, NAT/PAT and security services based on above.
High-performance RISC microprocessor architecture
Flash Memory 8MB, SDRAM 64MB
2 ports FXS analog voice interface
1 port of 10/100Mbps Ethernet interface for WAN connection
4 ports of 10/100Mbps switching hub interface
H/W based security accelerator (option) to reduce processing
Outstanding expandability and stability based on APOS with
